USA Lab -80 Degrees Celsius 30L Recirculating Chiller UC-30/80 42L/Min with Touchscreen PLC - USAlab

The USA Lab UC-30/80 is a powerful -80°C Chiller with a 30L Reservoir. This UC recirculating chiller is a true lab chiller ideal for applications involving vacuum systems, jacketed reactors, rotary evaporators, columns, solvent tanks, and even analytical instruments. The USA Lab UC-30/80 chillers offer unbeatable performance, ease of use and high reliability. These units keep quiet despite having a powerful pump allowing for constant flow rates to match the needs of demanding applications. ** Notice **NOT Compatible With 208V Power Input (Acceptable range: 219V - 253V) NOT intended for 24-hour operation, maximum operation time is 16 hours. SPECIFICATIONS Model UC-30/80 Reservoir Capacity 30L Reservoir Dimensions 13.7" x 13.7" Temperature Range Room Temp to -80°C / -112°F Power Requirements 220-240V 60Hz 30A 5250W Single Phase Control Type PLC Touchscreen Refrigeration BTUs 16,000BTU - 1,450BTU Circulating Pump Wattage 100W Temperature Accuracy +/- 0.5°C Pump Flow 42L/Min Lift (Max Pumping Height) 18.7ft Pump Pressure 2.5psi @ 3.9ft - 8.8psi @ 18.7ft Barb Size 5/8" Refrigerant R404 External Dimensions 39" x 31.9" x 48.4" Weight 473lbs Warranty 1 Year PACKING LIST Model Quantity USA Lab UC-30/80 -80°C Chiller 1 5/8" Insulated Tubing 11Ft 5/8" Barbed Valve 1 PTFE Sealing Tape 1 Manual 1 For Technical Support, Questions, or Other Issues Please Email or Call Us!

• The USA Lab UC-30/80 is a powerful -80°C Chiller with a 30L Reservoir
